Product Specifications for Carmix 2.5TT Self-Loading Mixer

Mixing Unit:
Drum capacity 3.450 liters. Concrete drum output: 2,5 m3. EN 206-1 IN SLUMP S1 Class,yield not vibrated. Double mixing screws, cover for emergency unloading. Drum rotation by hydraulic motor and planetary reducers. Mixing and discharging speed indipendent from r.p.m. of diesel engine.Discharging by reversing drum. The mixing unit is slewing hydraulically through 270° for high discharge at 1,9 m on the four sides of the vehicle
Engine:
Perkins 1104D-44T Turbo-Diesel, water-cooled, 4 cylinders. Rated power KW 62,5 (84 HP) set at 2.200 rpm. Engine mounted transversal on the rear
Transmission:
Hydrostatic Bosch Rexroth. Pump and motor are connected to the differentials through a 2 speed reducer (working and transfer). 4 wheel drive and steering
Axles:
Dana Spicer with oil bath disc brakes and planetary reducers
Speed (Electric servo control):
Working speed : 0 to 9 km/h
road transfer : 0 to 25 km/h
Cabin:
Front cab on side of loading shovel.ROPS-FOPS (UNI 11023) type complete with double closing door.Clima, air conditioning heater available upon request
Hydraulic System:
Three circuits. 2 variable outlet pumps for hydrostatic transmission and drum rotation.2 gear pumps for services. Inlet and outlet filter. Heat exchanger water/oil-air type
Joymix:
All hydraulic functions of shovel controlled by a single - fully servo controlled Joystick
Weighing:
Electronic system. “Load cells” acting on the drum, display and printer in the cab. (on request)
Promix:
In-drum probe, easy allows to anayze your concrete: slump, volume, temperature, humidity and ready-mix indicator: Your on site Lab! (on request)

Loading Shovel:
Effective capacity per load 400 liters, complete with hydraulic opening gate
Chute:
Slewing and hydraulically tilting. Fitted with two pins easily detachable to increase the discharge height
Water System:
Self-contained. Hydraulic driven water pump 400 lt/min, water meter, washing outlet.High pressure water pump (on request)
Gradient:
Fully loaded 30%
Brakes:
Oil bath disc brakes inside differential axles. Twin indipendent circuits. Negative hydraulic parking brake
Tyres:
Off road industrial type 12.5-20 PR 12
Steering:
Hydrostatic. 3 ways steering
Radius: internal: mm. 1500
external mm 3500
Electric System:
12 Volt. 120 Ah battery for electric starter and road lighting. Safety battery cut-off
Tanks:
Water: 2x270 liters
Diesel: 105 liters
Hydraulic oil: 80 liters
Chassis:
Steel profile specially engineered for off-road operations
Weight:
About Kg. 6.000. Equally distributed on both axles
Safety:
Machine equipped with checking and block valves for maximum safety of the operator. Self control avoids drum to slew if shovel’s arm is lifted
Catalogue:
The machine is equipped with Use and Manteinance and Spare Parts Manuals according to CE regulations

FAQs for Self-Loading Concrete Mixer 2.5TT

A self-loading concrete mixer combines material loading, concrete mixing, and transportation in one machine. It features a hydraulic loading shovel, an independent rotating drum, and 4-wheel drive, making it ideal for efficient concrete production on-site.

This mixer offers a 2.5 m³ drum capacity, 4-wheel drive and steering, a hydraulic-driven water pump, electronic weighing systems for precise measurements, and optional features like an in-drum probe for concrete analysis.

Equipped with an electronic weighing system and optional ProMix technology, the mixer can measure slump, volume, temperature, and humidity of the concrete. This guarantees accurate mixing and certifies the quality of the concrete on-site.

The machine features a steel-profile chassis, off-road industrial tyres, hydrostatic 3-way steering, and a 30% gradient handling capability. These features make it perfect for challenging terrains and remote construction locations.

Optional accessories include ProMix for concrete analysis, a high-pressure washing pump for easy cleaning, air conditioning for the operator's cabin, an additional discharge chute, and spare wheels.

The mixer is designed with low-maintenance components, such as oil-bath disc brakes and a self-contained water system with a high-pressure pump. The hydraulic system is efficient and easy to maintain, ensuring long-term reliability.

Carmix offers robust, user-friendly self-loading concrete mixers with advanced features like electronic weighing systems and ProMix technology. These machines are known for their durability, efficiency, and versatility, making them ideal for a wide range of construction projects.
